Dual Surface Resistivity Meter With Probes

About Dual Surface Resistivity Meter With Probes

Dual Surface Resistivity Meter With Probes The surface resistivity meter measures both surface resistance and resistance to ground. This is meant for use in evaluating a wide variety of ESD protective materials including table mats, floor mats, and hard ESD laminates. It measures and displays surface resistivity as well as surface to ground and point-to-point resistances. These measurements can be done in the range of < 103 to >1012 Ohms by using two 2.5 kilo (51b) heavy electrodes or through internal probes. To check whether surface resistivity is in accordance with EOS/ESD Association standards S-4.1.Specifications: Measurement Range (LCD) : 1 x 10^3 to 1 x 10^12 Ohms & Ohms / Sq Measurement Range (LED) : < 10^3 to > 10^12 Ohms / Sq Measurement Accuracy (LCD) : 0.1 Decade, Measurement Accuracy (LED) : 0.5 Decade Probe Voltage : 100V +/- 5%, Battery Indicator : Green when battery is fully charged Red for low battery Test actuation : Press To Read, Power Supply : 9V Rech Battery Dimensions in mm : 210 x 110 x 40 mm, Calibration : Calibration recommended once in 12 months Warranty : 12 Months from the date of manufacturer Optional : Testing & Measuring probes ESD Audit Kit Accessories : External cable & 12 V Charger
